How to replace a pool light
The short answer. You almost never need to drain the pool. An in-ground pool light is installed with enough cable coiled behind the niche to pull it out of the water and set it on the pool deck. Turn off the breaker, remove the top screw, pull out the light, perform the replacement on the deck, then put it back.
The only thing you should never do: turn on a pool light out of the water.
Before you start
Turn off the breaker at the panel. Not the wall switch, the breaker. And check that the light is off before going into the water.
Identify your voltage. If your system has a transformer, you are on 12 V. Otherwise, your light is probably powered by 120 V, and the job requires more precautions. If in doubt, hire someone to do it.
Plan for the right model. First, pull out the light, photograph its label, and then order. Ordering before checking is the leading cause of a project that drags on for a week.
Have a spare gasket on hand. The lens gasket almost always needs to be replaced, and it is what determines the seal for years to come.
The procedure, in-ground pool
1. Turn off the breaker.
2. Remove the retaining screw. It is usually at the top of the light's faceplate, inside the niche. It is often a flat-head or Phillips screw, sometimes corroded. A long-handled screwdriver helps a lot.
3. Free the light from its niche. It is lifted and pulled toward you. It is often tighter than you think after a few seasons.
4. Unroll the cable. This is the part that reassures everyone: there is cable coiled behind the niche, specifically to allow this operation. Pull gently and bring the light to the edge.
5. Set it on the deck, out of the water. On a towel, so as not to scratch the lens.
6. Perform the replacement. Open the light, replace the bulb or the entire light, change the gasket, and clean the gasket groove before closing. Tighten evenly, in a crisscross pattern, without forcing.
7. Test it before putting it back. Reconnect and turn it on very briefly, for a few seconds at most, only to confirm that it works. Never leave a light on in the open air: water is what cools it.
8. Cut the power again, then put it back. Push the cable back into the conduit, replace the light in its niche, and replace the retaining screw.
9. Turn the breaker back on and check that it works once the light is submerged.
The most important point: the extra cable
If you only remember one thing, remember this.
The cable coiled behind the niche is not extra that can be cut or shortened. It is what will allow the next intervention. A rushed installer who cuts this slack condemns the next replacement to a drop in the water level, or even construction work.
When putting it back, push the cable neatly back into the conduit without pinching it between the light and the niche.
The procedure, above-ground pool
It is simpler, and generally faster.
Many above-ground pool lights are mounted on the return or on the skimmer, without a recessed niche. The replacement is often done from outside the pool.
Some models, such as skimmer lights, sit without drilling anything or lowering the water level. It is the most accessible solution for adding lighting to an above-ground pool that does not have any.
The same electrical precautions apply: breaker off, never turn on in the open air.
See our above-ground pool lights
The gasket, the part we neglect
A pool light keeps the water out thanks to a single gasket. When it dries out, cracks, or deforms, water gets in.
Replace it every time you do a job, even if it looks fine. It is a part that costs a few dollars but protects an entire light.
Clean the groove before putting in the new gasket. A grain of sand is enough to create a path for water.
Lubricate with silicone, never with petroleum jelly or petroleum grease, which cause the rubber to swell and then rot.
Tighten evenly. Uneven tightening deforms the lens and creates a leak.
When not to do it yourself
Your light is powered by 120 V. The replacement requires additional precautions and a good understanding of the circuit.
The breaker or GFCI trips. There is an electrical fault, and replacing the light will not necessarily fix it.
The cable is damaged, or too short. Replacing a cable involves the conduit and the junction box, so it must be done by an electrician.
The niche is cracked or detached. This is structural work, not maintenance.
In Quebec, electrical work is regulated. Replacing a low-voltage light in its niche remains routine maintenance, but anything involving permanent wiring is not.
Frequently asked questions
Do you need to drain the pool to change a light?
No, almost never. The cable coiled behind the niche allows you to pull the light out to the edge of the pool. We only lower the water level if this cable has been shortened or if the niche needs to be replaced.
Can I turn the light on to test it before putting it back?
For a few seconds only, to confirm it works. A pool light is cooled by water, and leaving a light on in the open air will damage it.
My retaining screw is stuck due to corrosion. What should I do?
Do not force it to the point of breaking the screw head, which would make things much more complicated. A little patience, a properly fitted screwdriver, and a penetrating oil compatible with pool water will solve most cases.
How long does it take?
About thirty minutes for someone who has done it before, an hour for the first time. The screw is often what takes the longest.
Can I take advantage of this to switch to LED?
It is exactly the right time, since the light is already out. See converting your pool light to LED.
